Department has enough labs which are used for all the years on timetable basis to meet the curriculum requirements. The courses which have practical work are provided labs every week. Labs are equipped with sufficient hardware and software resources to run program (MATLAB) specific curriculum. Simulation lab/ Project Lab have been provided for the students to carry out their major project work.
The labs do have good ambience as the Experiments are arranged in a way that student can feel
Comfortable while doing







1. Electrical Circuits Lab
Regulated Power Supply -20
Ammeters-40
Voltmeters-45

kvsr






2. Electrical Circuits Simulation lab

Operating System: Windows
Software Used : MATLAB 2011

kvsr






3. Electrical Machines -I lab
DC MOTOR
5HP, 220V, 20A
DC GENERATOR
5HP, 220V, 20A

kvsr




4. Machines -II lab

Transformers-2KVA, 220V, 10A
Single phase Induction Motor- 5HP, 220V,7.5A
Three phase Induction Motor- 5HP,440V,7.5A
Alternator-5HP,440V,7.5A
Synchronous Motor-5HP,440V,7.5A

kvsr


5. Control Systems Lab

Synchronous Transmitter & Receiver,
Magnetic Amplifier,
DC Servo motor,
Ac Servo motor,
P,PI,PID Controllers

kvsr


6. Electrical Measurements Lab

Schering bridge,
Anderson’s bridge,
LVDT,
Phantom load,
Inductive Load,
Resistive Load

kvsr






7. Power Electronics Lab

Gate Firing Circuits for SCRs ,
Single Phase Half wave controlled converter with R,RL&RLE Load,
Single Phase Cycloconverter,
DC Jones Chopper with R and RL Loads,
Single Phase Parallel, Inverter with R and RL Loads,

kvsr






8. Power Systems Simulation Lab
Alternator-5HP,440V,7.5A,
Three Phase Auto Transformer 440V,10A

Number of Computers: 30
Operating System: Windows
Software Used : MATLAB 2012

kvsr








9. Project Lab
Number of Computers: 30
Operating System: WINDOWS
Software’s used: MATLAB 2012
